12V DPDT Relay

Overview

DPDT (Double Pole Double Throw) relay with 12V DC coil. Switches two independent circuits simultaneously. Contact rating 5A at 230V AC. Plug‑in or PCB mount.

Key Features

• Coil voltage: 12V DC
• Contact configuration: DPDT (2 form C)
• Contact rating: 5A @ 230V AC
• Plug‑in or PCB mount

Specifications

• Coil resistance: ~400–500Ω
• Pick‑up voltage: 70% of nominal

Dimensions & Weight

• Length: ~20 mm
• Width: ~15 mm
• Height: ~15 mm
• Weight: ~10 g

Package Includes

• 1 × 12V DPDT Relay

Applications

• Switching two independent circuits
• Industrial automation and control
• DIY electronics and signal routing
