Cytron SmartDrive Motor Driver – PWM 3A

Overview

Cytron SmartDrive motor driver with PWM control, supporting up to 3A continuous. Easy to use with Arduino, Raspberry Pi, and other microcontrollers. Features reverse polarity protection and built‑in current sensing.

Key Features

• 3A continuous, 4A peak
• Reverse polarity protection
• Built‑in current sensing
• Simple 2‑wire control (direction + PWM)

Specifications

• Supply Voltage: 6–30V
• Logic Voltage: 5V compatible

Dimensions & Weight

• Length: ~45 mm
• Width: ~30 mm
• Weight: ~20 g

Package Includes

• 1 × Cytron Motor Driver Module

Applications

• Robotics and mobile platforms
• Arduino and Raspberry Pi motor projects
• Educational and DIY electronics
